Automatic Clay Brick Machine Line-2ME194

Mechanical Equipment

Automatic Clay Brick Machine Line-2

自动黏土制砖机生产线-2

JKB50/50-30 two-stage de-airing brick extruder for 18,000–20,000 bricks per hour, for solid bricks and thin-walled hollow ware from clay, shale, coal gangue or fly ash blends.

Datasheet values listedThe values below come from the manufacturer datasheet or our catalogue. Final values are confirmed in the quotation and supporting documents.

Product details

Technical specifications

The extruder has an upper stage, a lower stage and a de-airing system. Clay compacted by the upper auger passes through the vacuum chamber, where the vacuum pump removes the air, and the lower auger extrudes it into a column of the required cross-section. Two extrusion passes with de-airing give dense green bricks with high compressive and shear strength. It shapes clay as well as shale, coal gangue or fly ash mixed with clay, and can also form sandy loam (plasticity index 7–10) and river or lake silt that ordinary extruders cannot shape.

Solid bricks and thin-walled hollow wareClay, shale, coal gangue and fly ash blendsSandy loam and river or lake silt

We confirm specifications and available configurations when preparing each quotation.

Product code
ME194
Catalogue category
Mechanical Equipment
Extruder model
JKB50/50-30
Capacity
18,000–20,000 bricks/h
Auger diameter (upper/lower)
550/500 mm
Extrusion pressure
20–30 kgf/cm²
Vacuum
≥92%
Power (upper/lower)
75/132 kW
Weight
18000 kg
Model
JKB50/50-30

Ordering

How to order this product

Prices are quoted per inquiry. Send the specification, quantity and destination and you receive a written quotation by e-mail, usually within two business days.

Minimum order
Confirmed in the quotation (ask us about trial quantities).
Lead time
Confirmed in the quotation, depending on quantity and configuration.
Packaging
Export packaging: rolls, cartons or pallets as required by the product and the shipment.
Port of loading
Shanghai, China (other ports on request).
Trade terms
EXW, FOB Shanghai, CFR or CIF, as stated in the quotation.
Payment
Bank transfer (T/T); letter of credit (L/C) negotiable for larger orders, as agreed in the quotation.
Samples
Available on request; sample and courier costs are confirmed before dispatch.
Documents
Commercial invoice, packing list, certificate of origin, test report or material certificate on request.
