Silica Fiber RopeSF206

Silica Fiber Products

Silica Fiber Rope

高硅氧纤维绳

Twisted or braided rope made from high-silica fibre (SiO2 about 96 %) for sealing furnace doors, kiln lids and expansion joints at continuous temperatures around 900–1000 °C.

Datasheet values listedThe values below come from the manufacturer datasheet or our catalogue. Final values are confirmed in the quotation and supporting documents.

Product details

Technical specifications

Silica fibre rope is manufactured from high-silica yarn, either twisted from several strands or braided over a silica or ceramic core. It is non-combustible, retains flexibility after heating and resists most chemicals except hydrofluoric acid and strong alkalis, so it serves as a gasket and packing where E-glass rope would soften: furnace and kiln door seals, boiler access covers, coke oven doors, expansion joint fillers and glass-plant equipment. Round section is standard; square section and metal-wire reinforced versions are available. Diameters from about 6 mm to 50 mm are supplied in coils.

Furnace and kiln door sealsBoiler and incinerator access coversExpansion joint and duct packingGlass and ceramic plant equipmentHeat-treatment furnace gaskets

We confirm specifications and available configurations when preparing each quotation.

Product code
SF206
Material
High-silica glass fibre yarn
SiO2 content
Approx. 96 % and above
Construction
Twisted or braided; square section on request
Diameter
Approx. 6–50 mm to order
Service temperature (typical)
Approx. 900–1000 °C continuous
Colour
White (natural)
Supply form
Coils of 10–30 m, carton packed

Ordering

How to order this product

Prices are quoted per inquiry. Send the specification, quantity and destination and you receive a written quotation by e-mail, usually within two business days.

Minimum order
Confirmed in the quotation (ask us about trial quantities).
Lead time
Confirmed in the quotation, depending on quantity and configuration.
Packaging
Export packaging: rolls, cartons or pallets as required by the product and the shipment.
Port of loading
Shanghai, China (other ports on request).
Trade terms
EXW, FOB Shanghai, CFR or CIF, as stated in the quotation.
Payment
Bank transfer (T/T); letter of credit (L/C) negotiable for larger orders, as agreed in the quotation.
Samples
Available on request; sample and courier costs are confirmed before dispatch.
Documents
Commercial invoice, packing list, certificate of origin, test report or material certificate on request.

For an accurate quotation

Include the operating and delivery requirements that affect product selection.

When available, attach a specification sheet, drawing or reference sample details in your message.

01Material or grade

Required construction, coating, compound or reference grade.

02Dimensions and format

Thickness, width, length, diameter, weight or finished format.

03Operating conditions

Temperature, pressure, media, movement and service environment.

04Quantity and destination

Required quantity, delivery country and requested timing.

05Standards and documents

Applicable standard, test report, material certificate or origin document.
